27.00mm TiAIN Micrograin Carbide 140 Deg. Included Angle Through Coolant Replaceable Drill Tip

  • Item Code: 0019009
  • Brand: Dormer
  • Unit Size: 1

Description

Another member of Dormer?s Hydra drilling range, R960 drill heads are manufactured from premium carbide for high performance drilling and longer tool life. The interchangeable heads with coolant feed mean you can replace just the Hydra drill head for great cost savings. With a geometry designed specifically for drilling stainless steels, R960 Hydra drill heads come with a 140 degree split point to help with self-centering and reduce the push force needed, and a special Tiphon coating to extend the tool life and give improved performance when drilling harder materials. Please see H853, H855 and H858 Hydra bodies for use with these drill heads.

Features Tech Specs

Features

Back To Top
    • Replaceable heads in tough micro-grain carbide for quick and easy tool changes
    • High productivity in a wide range of stainless steel, cast iron & heat resistant materials
    • Superior hole accuracy and precise repeatable tolerances
    • Special Ti-phon coating for longer tool life

Tech Specs

Back To Top
Decimal Diameter 1.063"
Metric Diameter 27 mm
Material Solid Carbide
Point Angle 140 Deg.
Cutting Direction Right
Product Type Replaceable Drill Tip
Brand Dormer
Coating/Finish Ti-phon
