25.00 mm HSS Bright Finish 82 Deg. 3 Flute Countersink

  • Item Code: 0149409
  • Brand: Dormer
  • Unit Size: 1

Description

Countersink with 3-flutes, 82? chamfering angle, maximum diameter 25.00mm with an overall length of 67mm and a head length of 15.5mm and 10mm straight shank, according to DIN 335 C standard to produce a conical seat for US standard countersunk-head screws with a minium hole diameter of 3.80mm, HSS with standard bright finish for machining free machining, plain carbon and alloy steel, copper or copper alloys

Features Tech Specs

Features

Back To Top
    • 82� countersink for multiple materials
    • Bright finish improves chip flow in soft ferrous or non-ferrous materials

Tech Specs

Back To Top
Coating/Finish Bright
Metric Diameter 25.00 mm
Shank Style Cylindrical shank
Brand Dormer
Material High Speed Steel
Overall Length Metric 67 mm
Cutting Direction Right
Number of Flutes 3
Overall Length Inches 2.6378"
Point Angle 82 Deg.
