8.50 Inch x 11 Inch, Lapping Film 461X, 9.0 Micron Sheet, 50 per inner 200 per case
- Item Code: 051144-50093
- Brand: 3M
- Unit Size: 50
Description
Silicon carbide mineral coated on a 3 mil polyester film. Available in 5.0, 9.0, 15.0, & 30.0 micron and is our standard product for silicon carbide related polishing applications in the fiber optic and metallurgical industries.
Features
Back To Top- Consistent cut rate, finish and life
- Available in discs, sheets and rolls
Tech Specs
Back To Top| Attachment Type | Plain Back |
|---|---|
| Connector Type | Ceramic Fiber Optic Connectors |
| Dimension 1 | 8 1/2 Inch |
| Inner Cubic Dimension (FTQ) | 0.081 |
| Inner Depth/Length | 1 |
| Inner Gross Weight | 1.25 |
| Inner Height | 10 |
| Inner UPC | 30051144500933 |
| Inner Width | 14 |
| Length | 11 Inch |
| Micron Grade | 9.00 |
| Product Series | 461X |
| Size Description | 8 1/2 in x 11 in |
| Substrates | Ceramics;Glass;High-Hardness Metals;Metal;Optical Substrates;Plastic;Silicon Carbides |
| Width | 8.5 Inch |
| Mineral Type | Silicon Carbide |
| Inner Pack Level Quantity | 50 |
| Color | Gray |
| Dimension 2 | 11 Inch |
| Inner Total Base Units | 50 |
| Inner Total Pack Level Units | 50 |
| Series | 3M |
| Product Form | Sheet |
| Brand | 3M |
