1/2 Inch x 20 Feet, Vinyl Color Coding Electrical Tape 35, Green

  • Item Code: 054007-10265
  • Brand: 3M
  • Unit Size: 1

Description

Features Tech Specs

Features

Back To Top
    • UL Listed and CSA Certified
    • 7-mil thick polyvinyl chloride (PVC) color-coding tape
    • Temperature range of 32��220�F (0��105�C)
    • Excellent for use in phase identification, color coding of motor leads and piping systems, and for marking safety areas
    • Abrasion- and weather-resistant
    • Flame-retardant; resists UV rays, abrasion, moisture, alkalies, solvents, many acids
    • Stretches to conform to virtually any shape

Tech Specs

Back To Top
Breaking Strength 17
Length (Metric) 6.1 m
Operating Temperature Range (Fahrenheit) 32 to 220 Degree Fahrenheit
Size Description 1/2 in x 20 ft
Vulcanizing No
Brand 3M
Dimension 1 1/2 in
Thickness 7 mil
Width 0.5 Inch
Adhesive Material Rubber Resin
Backing Material Polyvinyl Chloride
Series Scotch
Dielectric Strength 1250 V/mil
Dimension 2 20 ft
Insulated Yes
Length 20 Linear Foot
Product Type Vinyl Tape
Specifications VDE 0340-TEIL1
Agency Approvals UL Listed
Tape Grade Premium
Thickness (Metric) 0.177 mm
Color Green
Operating Temperature Range (Celsius) 0 to 105 Degree Celsius
Voltage Application Low Voltage
Width (Metric) 12 mm
Material PVC
Tape Type Vinyl
UV Resistant Yes
