1-2 Inch, .0001 Inch Mechanical Outside Micrometer, Hammertone Baked Enamel, Ratchet Stop, With Standard

  • Item Code: 103-132
  • Brand: Mitutoyo
  • Unit Size: 1

Description

Features Tech Specs

Features

Back To Top
    • Ratchet Stop for exact repetitive readings.
    • Hammertone, baked-enamel-finished frame
    • Comes with a standard bar.

Tech Specs

Back To Top
Accuracy ±.0001 In
Mechanical or Digital Mechanical
Primary (Outside Diameter) Contact Point Material Carbide
Range 1 - 2 In
Contact Point Diameter 6.35mm
Primary Measuring Range Upper - Inch 2 In
Thimble Diameter Measurement 18mm
Case Material Plastic Case
Clutch Ratchet Stop
Primary Measuring Range Lower - Inch 1 In
Resolution or Graduation .0001 In
Spindle Face Flat
Contact Point Flatness .000024 In
Finish Enamel
Brand Mitutoyo
Case Part Number 475003
Parallelism [.00008+.00004(L/4)]In
Individual or Set Individual
