5-6 Inch Measuring Range, 0.001 Graduation, Ratchet Thimble, Carbide Face, Outside Micrometer

  • Item Code: 103-182
  • Brand: Mitutoyo
  • Unit Size: 1

Description

Features Tech Specs

Features

Back To Top
    • Hammertone, baked enamel-finished-frame.
    • Ratchet Stop for exact repetitive readings.

Tech Specs

Back To Top
Clutch Ratchet Stop
Accuracy ±.00015 In
Thimble Diameter Measurement 18mm
Brand Mitutoyo
Primary Measuring Range Upper - Inch 6 In
Contact Point Diameter 6.35mm
Mechanical or Digital Mechanical
Case Part Number 475005
Contact Point Flatness .000024 In
Finish Enamel
Primary (Outside Diameter) Contact Point Material Carbide
Case Material Plastic Case
Parallelism [.00008+.00004(L/4)]In
Primary Measuring Range Lower - Inch 5 In
Resolution or Graduation .001 In
Spindle Face Flat
Individual or Set Individual
Range 5 - 6 In
Spindle Lock Y
