8-9 Inch Measuring Range, 0.001 Graduation, Ratchet Thimble, Carbide Face, Outside Micrometer

  • Item Code: 103-185
  • Brand: Mitutoyo
  • Unit Size: 1

Description

Features Tech Specs

Features

Back To Top
    • Hammertone, baked enamel-finished-frame.
    • Ratchet Stop for exact repetitive readings.

Tech Specs

Back To Top
Case Material Plastic Case
Primary Measuring Range Lower - Inch 8 In
Range 8 - 9 In
Spindle Face Flat
Clutch Ratchet Stop
Case Part Number 475005
Individual or Set Individual
Spindle Lock Y
Contact Point Flatness .000024 In
Primary (Outside Diameter) Contact Point Material Carbide
Accuracy ±.0002 In
Brand Mitutoyo
Contact Point Diameter 6.35mm
Mechanical or Digital Mechanical
Parallelism [.00008+.00004(L/4)]In
Primary Measuring Range Upper - Inch 9 In
Resolution or Graduation .001 In
Thimble Diameter Measurement 18mm
Finish Enamel
