12-13 Inch Measuring Range, 0.001 Graduation, Ratchet Thimble, Carbide Face, Outside Micrometer

  • Item Code: 103-189
  • Brand: Mitutoyo
  • Unit Size: 1

Description

Features Tech Specs

Features

Back To Top
    • Hammertone, baked enamel-finished-frame.
    • Ratchet Stop for exact repetitive readings.

Tech Specs

Back To Top
Primary Measuring Range Lower - Inch 12 In
Primary Measuring Range Upper - Inch 13 In
Range 12 - 13 In
Case Part Number 475005
Mechanical or Digital Mechanical
Primary (Outside Diameter) Contact Point Material Carbide
Brand Mitutoyo
Individual or Set Individual
Parallelism [.00008+.00004(L/4)]In
Resolution or Graduation .001 In
Contact Point Diameter 6.35mm
Contact Point Flatness .000024 In
Finish Enamel
Thimble Diameter Measurement 18mm
Case Material Plastic Case
Clutch Ratchet Stop
Spindle Face Flat
Spindle Lock Y
Accuracy ±.0003 In
