ISO 30 X ER 40 - CMS without Nut Collet Chuck
- Item Code: 12040-CMS
- Brand: Techniks
- Unit Size: 1
Description
Techniks Collet Chucks are balanced to 25,000 RPM at G2.5 tolerance. They are individually lab tested for accuracy and balance and come with their individual performance report. Techniks holders achieve 0.0001" or less T.I.R. as measured from the taper to the collet pocket. Taper is ground to AT3 accuracy or better.
Features
Back To Top- Balanced to 40,000 RPM at G2.5
- Certified for accuracy and balance
- "Power Coat" collet nut included
Tech Specs
Back To Top| Body Diameter-Workpiece Side (in) | 2.48 |
|---|---|
| Gage Length (in) | 2.6 |
| Gage Length (mm) | 66 |
| Gage Length-Face Contact (mm) | 62.8 |
| Overall Length (in) | 4.48 |
| Overall Length (mm) | 113.8 |
| Brand | Techniks |
| Capacity Range (mm) | 2.2 - 26mm |
| Collet Series | ER40 |
| Lock Nut Diameter (in) | 2.48 |
| Overall Diameter (mm) | 46 |
| Balanced to | 25,000 RPM at G2.5 |
| Lock Nut Diameter (mm) | 63 |
| Taper | ISO30 |
| Overall Diameter (in) | 1.81 |
| Gage Length-Face Contact (in) | 2.47 |
| Material | 8620 Steel |
| Unit of Tool | Metric or Inch |
| Body Diameter-Workpiece Side (mm) | 63 |
| Capacity Range (in) | 0.086" - 1.02" |
| Style | Single Ended |
| Type | V-Flange Collet Chuck |
