4.1mm Width x 32.0mm Height ProGroove Cut Off Blade Holder
- Item Code: 12251354000-W
- Brand: WIDIA
- Unit Size: 1
Description
ProGroove™ Cut-Off Blades
Tech Specs
Back To Top| Catalog Groove Width (Metric) | 4.100 |
|---|---|
| Cutting Height (Metric) | 25.000 |
| Shank Width (Metric) | 3.200 |
| Tool Length (Fraction) | 5.9055 |
| Tool Length (Inch) | 5.9055 |
| Tool Length (Metric) | 150.000 |
| Shank Width (Inch) | 0.1260 |
| Cutting Height (Inch) | 0.98425 |
| Material | Steel |
| Catalog Groove Width (Inch) | 0.1614 |
| Shank Height (Inch) | 1.2598 |
| Units of Tool (Extract) | MM - Metric |
| Adapter Size Machine Side-EPP | 0320 |
| Clamping Type | Y - A2/A3/A4/PG/TG Clamping |
| Lead Angle ANSI | 0.000 |
| Toolholder Shape | S - Straight |
| Adapter Style Machine Side | Toolholder |
| Brand | WIDIA |
| Lead Angle ISO | 90.000 |
| Product Type | Cut-Off |
| Shank Height (Metric) | 32.000 |
| Adapter Style Machine Side-EPP | PMK-02 Cutoff Sup Bld A1-A3 |
| Adapter Type Machine Side-EPP | PMK - Prismatic Adapter Kenna |
| Cutting Depth (Inch) | 1.9685 |
| Cutting Depth (Metric) | 50.000 |
