3/8 Inch Diam, 1 Inch Length of Cut, 4 Flute, Solid Carbide TiAlN Coated Center Cutting TuffCut® GP Ball Nose End Mill
- Item Code: 14037500A
- Brand: MA Ford
- Unit Size: 1
Description
Tuff Cut® GP - Series 140 Coated
Manufactured with a full ball radius end.
Features
Back To Top- Designed for milling fillets or similar rounded corners in the bottom of a cut.
- Ideal for most ferrous metal applications.
Tech Specs
Back To Top| Coating/Finish | AlTiN |
|---|---|
| Overall Length | 2-1/2 Inch |
| Decimal Diameter | 0.3750" |
| Fractional Diameter | 3/8" |
| Helix Angle | 30° |
| Material | Solid Carbide |
| Number of Flutes | 4 |
| Length of Cut | 1 Inch |
| Series | Tuff Cut® GP |
| Type | End Mill |
| Brand | MA Ford |
| Shank Diameter | 3/8 Inch |
