12mm Diameter, 25mm Length of Cut, 76mm Overall Length 4-Flute Solid Carbide TiAlN Coated Center Cutting TuffCut® GP Ball Nose End Mill
- Item Code: 14047240A
- Brand: MA Ford
- Unit Size: 1
Description
Tuff Cut® GP - Series 140 Coated
Manufactured with a full ball radius end.
Features
Back To Top- Designed for milling fillets or similar rounded corners in the bottom of a cut.
- Ideal for most ferrous metal applications.
Tech Specs
Back To Top| Length of Cut | 25mm |
|---|---|
| Overall Length | 76mm |
| Shank Diameter | 12mm |
| Type | End Mill |
| Coating/Finish | AlTiN |
| Series | Tuff Cut® GP |
| Decimal Diameter | 0.4724" |
| Brand | MA Ford |
| Material | Solid Carbide |
| Metric Diameter | 12.00 mm |
| Helix Angle | 30° |
| Number of Flutes | 4 |
