3/8-16 (One ea: Plug-Taper-Bot) Uncoated 4 Flute H3 HSS Hand Tap Set
- Item Code: 14164
- Brand: WIDIA
- Unit Size: 1
Description
Series 5303
Hand Taps
Through or Blind Holes in General Machining Applications
Features
Back To Top- Production Taps
- Fractional Sizes
- Plug Chamfer
Tech Specs
Back To Top| Chamfer | Plug |
|---|---|
| Thread Limit | H3 |
| Coating | Uncoated |
| Number of Flutes | 4 |
| Brand | WIDIA |
| Material | HSS |
| Shank Style | Square |
| Unit of Measure | Inch |
| Threads Per Inch | 16 |
| Type | Hand |
| Square Size | 0.2860 Inch |
| Product Name | Tap |
| Thread Length | 1.2500 Inch |
| Diameter | 3/8 - 16 |
| Overall Length | 2-15/16 Inch |
| Shank Diameter | 0.3810 Inch |
| Thread Type | NC/UNC/UNJC |
