2.4 hp, Straight-Line, 13,000 RPM, Rear Exhaust, for 2 Inch W x 34 Inch L (51 mm x 864 mm) Belts, Dynangle II Abrasive Belt Tool, Dual Motor w/Platen

  • Item Code: 14303-DYNABRADE
  • Brand: Dynabrade
  • Unit Size: 1

Description

Polish, grind contours and flats. Surface conditions stainless steel and most other metals. Also used on wood, plastic, fiberglass and composites. Blends and finishes solder seams. Built-in abrasive belt guard; fast belt change.

Features Tech Specs

Features

Back To Top
    • Heavy-Duty 'Dual Motor' with Platen offers extra power. Uses 2" x 34" belts; belts spans 11-1/2" for 'strap polishing' up to 36" diameter pipe.
    • Includes 2" wide x 6" long platen which is easily removed for strap polishing.

Tech Specs

Back To Top
Belt Size Inches (mm) 2" (51) W x 34" (864) L
Height Inches (mm) 9-9/16" (243)
Length Inches (mm) 18-7/8" (479)
Max. SFPM (SM/Min.) 8,500 (2,591)
Brand Dynabrade
Exhaust Type Rear Exhaust
Hose I.D. Size Inches (mm) 1/2" (13)
Motor Style Straight-Line
Air Inlet Thread 1/2" NPT
hp (W) 2.0 (1,492)
Motor Free Speed (RPM) 13,000
