3/4-10 Uncoated 4 Flute H3 HSS Taper Chamfer 7-10 Pitch Left Hand Tap
- Item Code: 14452
- Brand: WIDIA
- Unit Size: 1
Description
Series 5303
Hand Taps
Through or Blind Holes in General Machining Applications
Features
Back To Top- Production Taps
- Fractional Sizes
- Plug Chamfer
Tech Specs
Back To Top| Chamfer | Plug |
|---|---|
| Overall Length | 4-1/4 Inch |
| Shank Diameter | 0.5900 Inch |
| Square Size | 0.4420 Inch |
| Thread Length | 2 Inch |
| Thread Limit | H3 |
| Threads Per Inch | 10 |
| Material | HSS |
| Number of Flutes | 4 |
| Type | Hand |
| Product Name | Tap |
| Thread Type | NC/UNC/UNJC |
| Diameter | 3/4 - 10 |
| Shank Style | Square |
| Brand | WIDIA |
| Coating | Uncoated |
| Unit of Measure | Inch |
