125mm Length, BT40 ER16 Hex Nut Collet Chuck
- Item Code: 16155-TECHNIKS
- Brand: Techniks
- Unit Size: 1
Description
Techniks Collet Chucks are balanced to 25,000 RPM at G2.5 tolerance. They are individually lab tested for accuracy and balance and come with their individual performance report. Techniks holders achieve 0.0001" or less T.I.R. as measured from the taper to the collet pocket. Taper is ground to AT3 accuracy or better.
Features
Back To Top- Balanced to 25,000 RPM at G2.5
- T.I.R. 0.0001" measured from taper to collet pocket
- PowerCOAT nut included for 75% more clamping power
Tech Specs
Back To Top| Gage Length (mm) | 125 |
|---|---|
| Gage Length-Face Contact (in) | 4.84 |
| Gage Length-Face Contact (mm) | 123 |
| Overall Length (in) | 7.49 |
| Overall Length (mm) | 190.2 |
| Overall Diameter (in) | 2.48 |
| Balanced to | 25,000 RPM at G2.5 |
| Material | 8620 Steel |
| Taper | BT40 |
| Unit of Tool | Metric or Inch |
| Gage Length (in) | 4.92 |
| Overall Diameter (mm) | 63 |
| Lock Nut Diameter (mm) | 32 |
| Brand | Techniks |
| Style | Single Ended |
| Type | V-Flange Collet Chuck |
| Body Diameter-Workpiece Side (mm) | 28 |
| Capacity Range (mm) | 0.5 - 10.5mm |
| Collet Series | ER16 |
| Lock Nut Diameter (in) | 1.26 |
| Body Diameter-Workpiece Side (in) | 1.102 |
| Capacity Range (in) | 0.019" - 0.41" |
