.0220 Inch Uncoated Carbide, 2-Flute, Series 1620 Stub Length GP Square End Mill
- Item Code: 1620-0220.033
- Brand: KYOCERA
- Unit Size: 1
Description
Mirror Surface Finishes
Sub Micron Grain Carbide
Tol. D = +0.000" / -0.001"
Features
Back To Top- 2 Flute Stub Length Square End Mills
- General Purpose Machining
Tech Specs
Back To Top| Application | Roughing/Finishing |
|---|---|
| Length of Cut | .0330" |
| Shank Diameter | .125" |
| Style | Square End |
| Helix Angle | 30° |
| Brand | KYOCERA |
| Flute Spiral Directon | Right Hand |
| Shank Type | Straight |
| Decimal Diameter | 0.0320" |
| Overall Length | 1-1/2" |
| Coating/Finish | None |
| Material | Solid Carbide |
| Number of Flutes | 2 |
| Series | 1620 |
