12mm Diameter Stub Length Solid Carbide TiAlN Coated, TuffCut® GP 4 Flute Ball Nose End Mill
- Item Code: 16547240A
- Brand: MA Ford
- Unit Size: 1
Description
TuffCut® GP - Series 165
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Aluminum titanium nitride (AlTiN) is one of the most abrasive resistant and hardest of the coatings. It is commonly used for machining aircraft and aerospace material, nickel alloy, stainless steel, titanium, cast iron and carbon steel.
Features
Back To Top- 30 Degree helix
- Designed for aggresssive milling of most materials with reduced deflection and improved tool life and overall economy
- Manufactured with full ball radius end.
Tech Specs
Back To Top| Number of Flutes | 4 |
|---|---|
| Type | End Mill |
| Length of Cut | 16.0mm |
| Series | Tuff Cut® GP |
| Brand | MA Ford |
| Coating/Finish | AlTiN |
| Overall Length | 64mm |
| Decimal Diameter | 0.4724" |
| Material | Solid Carbide |
| Metric Diameter | 12.00 mm |
| Shank Diameter | 12.0mm |
| Helix Angle | 30° |
