M6 x 1 HSS TiN Coated 3-Flute D5 Plug Spiral-Flute Tap
- Item Code: 19933
- Brand: WIDIA
- Unit Size: 1
Description
Series 5364
Plug Chamfer
Blind Holes in Machining Applications
Features
Back To Top- Production Tap
Tech Specs
Back To Top| Flute Style | Helix |
|---|---|
| Number of Flutes | 3 |
| Overall Length | 2-1/2 Inch |
| Shank Style | Square |
| Brand | WIDIA |
| Product Name | Tap |
| Unit of Measure | Inch |
| Thread Type | METRIC |
| Chamfer | Plug |
| Coating | TiN |
| Thread Limit | D5 |
| Coolant Through (Yes/No) | No |
| Diameter | M6 X 1 |
| Hand of Tool | Right Hand |
| Shank Diameter | 0.2550 Inch |
| Square Size | 0.1910 Inch |
| Thread Length | 0.6250 Inch |
| Pitch | 1.00 MM |
