1/32 Inch Diameter, 1/8 Inch LOC, 1-1/2 Inch OAL, Carbide Down Cut, Fishtail Point Diamond Grind Router Bit
- Item Code: 23103120F
- Brand: MA Ford
- Unit Size: 1
Description
Diamond Grind Routers - Series 231F
Down Cut - Fishtail Point
Designed for routing of glass-reinforced printed circuit boards, phenolic-epoxy and other highly abrasive materials.
Features
Back To Top- Ultra fine micrograin carbide.
- Routers are available with color coded depth setting rings upon request.
Tech Specs
Back To Top| Number of Flutes | Diamond Grd. |
|---|---|
| Type | Diamond Grind Router |
| Material | Solid Carbide |
| Brand | MA Ford |
| Decimal Diameter | 0.0312" |
| Fractional Diameter | 1/32" |
| Overall Length | 1-1/2 Inch |
| Shank Diameter | 1/8 Inch |
| Length of Cut | 1/8 Inch |
