1 to 2 Inch Range, 0.0001 Inch Resolution, Standard Throat, IP65 Electronic Outside Micrometer

  • Item Code: 293-345-30
  • Brand: Mitutoyo
  • Unit Size: 1

Description

Features Tech Specs

Features

Back To Top
    • Measurement data output function is available with a water-resistant connection cable.
    • Auto power ON/OFF function.
    • Certificate of inspection is included.

Tech Specs

Back To Top
Case Part Number 04MAA214
Individual or Set Individual
IP Rating IP65
Parallelism .00004 In
Primary (Outside Diameter) Contact Point Material Carbide
Resolution or Graduation .00005 In
Contact Point Flatness 0.000012 In
Data Output N
Primary Measuring Range Lower - Metric 25.4mm
Accuracy ±.00005 In
Finish Enamel
Case Material Plastic Case
Primary Measuring Range Lower - Inch 1 In
Primary Measuring Range Upper - Inch 2 In
Primary Measuring Range Upper - Metric 50.8mm
Spindle Face Flat
Clutch Ratchet Thimble
Contact Point Diameter 6.35mm
Mechanical or Digital Digimatic
Range 1 - 2 In/25.4mm - 50.8mm
Spindle Lock Y
Brand Mitutoyo
Thimble Diameter Measurement 18mm
