Tappet Satin Open-End Wrench - 12 x 13 mm - Facom®

  • Item Code: 31.12X13
  • Brand: Proto
  • Unit Size: 1

Description

Satin finish provides corrosion resistance and a slip resistant grip.

Used to tighten collars, lock nut rings and help seal packing nuts on hydraulic cylinders.

Ultra thin profile for use in close quarters.

Openings designed to cover tappets, screws and lock nuts with excessive overhang which helps improve access.

For use in low torque applications.

Standard open end configuration.

Features Tech Specs

Features

Back To Top
    • Satin finish provides corrosion resistance and a slip resistant grip.
    • Used to tighten collars, lock nut rings and help seal packing nuts on hydraulic cylinders.
    • Ultra thin profile for use in close quarters.
    • Openings designed to cover tappets, screws and lock nuts with excessive overhang which helps improve access.
    • For use in low torque applications.
    • Standard open end configuration.

Tech Specs

Back To Top
Box Length [in] 8.600
Head Outside Width [in] 1-7/64
Head Thickness 1 [in] 1-3/32
Head Thickness 1 [mm] 3.6
Head Thickness 2 [in] 1-3/32
Head Thickness 2 [mm] 3.6
Outside Head Width 1 [in] 1-7/64
Outside Head Width 1 [mm] 28
Overall Length [in] 8-17/64
UPC Code 662679981389
Outside Head Width 2 [in] 8-9/32
Box Weight [lbs] 1.050
Finish Satin
Item Length [in] 8.400
Box Width [in] 1.500
Country of Origin Italy
Size [mm] 12 x 13
Box Height [in] 0.400
Item Width [in] 1.300
Item Height [in] 0.200
Length [in] 210
Brand Proto
Harmonization Code 8204110030
Item Quantity 1
Outside Head Width 2 [mm] 33
Item Weight [lbs] 0.170
Box Quantity 6
