Tappet Satin Open-End Wrench - 18 x 19 mm - Facom®

  • Item Code: 31.18X19
  • Brand: Proto
  • Unit Size: 1

Description

Satin finish provides corrosion resistance and a slip resistant grip.

Used to tighten collars, lock nut rings and help seal packing nuts on hydraulic cylinders.

Ultra thin profile for use in close quarters.

Openings designed to cover tappets, screws and lock nuts with excessive overhang which helps improve access.

For use in low torque applications.

Standard open end configuration.

Features Tech Specs

Features

Back To Top
    • Satin finish provides corrosion resistance and a slip resistant grip.
    • Used to tighten collars, lock nut rings and help seal packing nuts on hydraulic cylinders.
    • Ultra thin profile for use in close quarters.
    • Openings designed to cover tappets, screws and lock nuts with excessive overhang which helps improve access.
    • For use in low torque applications.
    • Standard open end configuration.

Tech Specs

Back To Top
Head Outside Width [in] 1-33/65
Head Thickness 2 [mm] 4.2
Outside Head Width 1 [mm] 38.5
Outside Head Width 2 [mm] 43
Size [mm] 18 x 19
UPC Code 662679981419
Box Width [in] 4.000
Country of Origin Italy
Finish Satin
Item Length [in] 9.800
Box Quantity 6
Box Height [in] 1.000
Box Weight [lbs] 1.800
Item Height [in] 0.200
Item Weight [lbs] 0.300
Box Length [in] 10.000
Brand Proto
Head Thickness 1 [in] 1-17/32
Head Thickness 2 [in] 1-17/32
Item Width [in] 1.700
Outside Head Width 2 [in] 1-11/16
Harmonization Code 8204110030
Head Thickness 1 [mm] 4.2
Item Quantity 1
Length [in] 249
Outside Head Width 1 [in] 1-33/64
Overall Length [in] 9-27/32
