0.2 Inch - 0.8 Inch, Graduation 0.001 Inch V-Anvil Micrometer

  • Item Code: 3290-083
  • Brand: Insize
  • Unit Size: 1

Description

Features Tech Specs

Features

Back To Top
    • Measure the outside diameter of cutting tools
    • (such as taps, reamers, end mills) with 3 or 5 flutes.
    • Graduation .001". Ratchet stop.
    • Carbide measuring faces. Supplied with setting standards.

Tech Specs

Back To Top
Minimum Measurement 0.2 in
Number of Flutes Measured 3
Rotating Spindle Non-Rotating
Head Diameter 18 mm
Anvil Type V-Anvil
Data Output Non
Graduation 0.001 in
Measuring Face Material Carbide
Type V-Anvil
Spindle Diameter 6.5 mm
Digital Counter None
Spindle Type Point
Maximum Measurement 0.8 in
Brand Insize
Measurement Type Mechanical
Point Angle 60 °
Thimble Type Ratchet Stop
