1 Inch - 2 Inch(25-50mm), 0.00005 Inch(0.001mm) Digimatic Caliper Jaw Type Micrometer, Carbide Steel Tip, Locking Clamp, With SPC Data Output, Ratchet Stop

  • Item Code: 345-351-30
  • Brand: Mitutoyo
  • Unit Size: 1

Description

Features Tech Specs

Features

Back To Top
    • Caliper type jaws are made of high-grade, tool steel
    • Locking clamp for positive locking of spindle
    • Satin Chrome finish.

Tech Specs

Back To Top
Primary Measuring Range Lower - Metric 25mm
Range 1 - 2 In / 25-50mm
Data Output Y
Data Output Cable - 40 inch 05CZA662
Data Output Cable - 80 inch 05CZA663
Brand Mitutoyo
Mechanical or Digital Digimatic
Primary Measuring Range Upper - Metric 50mm
Case Part Number 04MAA174
Primary Measuring Range Upper - Inch 2 In
Individual or Set Individual
Primary (Outside Diameter) Contact Point Material Carbide
Accuracy ±.0003 In
Primary Measuring Range Lower - Inch 1 In
Spindle Lock N
Case Material Plastic Case
Resolution or Graduation .00005 In
