0-1 Inch/0-25.4mm, .00005 Inch/0.001mm Digimatic Spherical Face Micrometer, Carbide Steel Tip, 4.7mm Diameter Spherical Anvil, With SPC Data Output, Ratchet Stop

  • Item Code: 395-363-30
  • Brand: Mitutoyo
  • Unit Size: 1

Description

Features Tech Specs

Features

Back To Top
    • Designed to measure the wall thickness of vaious tubing.
    • With Ratchet Stop for constant force.
    • IP65 water/dust protection.

Tech Specs

Back To Top
Case Material Plastic Case
Primary Measuring Range Upper - Inch 1 In
Spindle Face Flat
Data Output Cable - 80 inch 05CZA663
IP Rating IP65
Resolution or Graduation .00005 In
Accuracy ±.00015 In
Primary Measuring Range Lower - Inch 0 In
Contact Point Diameter Special
Primary (Outside Diameter) Contact Point Material Carbide
Primary Measuring Range Lower - Metric 0mm
Data Output Y
Thimble Diameter Measurement 18mm
Brand Mitutoyo
Case Part Number 04MZA198
Clutch Ratchet Stop
Primary Measuring Range Upper - Metric 25.4mm
Contact Point Flatness .000024 In
Finish Enamel
Individual or Set Individual
Data Output Cable - 40 inch 05CZA662
Mechanical or Digital Digimatic
Range 0 - 1 In/0 - 25.4mm
Spindle Lock Y
