31.0 mm HSS TiAIN Coated RH 3 Flute 90 Deg. Single End Countersink
- Item Code: 5973349
- Brand: Dormer
- Unit Size: 1
Description
Countersink with 3-flutes, 90? chamfering angle, maximum diameter 31.00mm with an overall length of 71mm and a head length of 18.5mm and 12mm straight shank, according to DIN 335 C standard to produce a conical seat for ISO Metric countersunk-head screws with a minium hole diameter of 4.20mm, HSS with standard TiAlN coating for machining free machining, plain carbon, alloy and tool steel, grey, malleable, ductile and compacted graphite cast-iron, cast aluminium and copper or copper alloys
Tech Specs
Back To Top| Point Angle | 90 Deg. |
|---|---|
| Material | High Speed Steel |
| Metric Diameter | 31.00 mm |
| Coating/Finish | TiAlN |
| Cutting Direction | Right |
| Number of Flutes | 3 |
| Overall Length Inches | 2.7953" |
| Overall Length Metric | 71 mm |
| Shank Style | Cylindrical shank |
| Brand | Dormer |
