4 mm x 0 mm Coarse Cobalt (HSS-E) Gold Finish 3 Flute RH Semi-Bottoming Chamfer Spiral Flute Tap
- Item Code: 5973801
- Brand: Dormer
- Unit Size: 1
Description
Spiral flute tap with chamfer form C with a 2-3xP semi-bottoming lead, for ISO-Metric thread M4 with 0.70 mm pitch and 6H class of fit, dimensions according to ANSI standard with 0.1680" shank and 0.1310" square drive, powder metallurgical HSS-E with bright finish and 45? helix angle for 2.5xD blind hole threading in free machining and plain carbon steel and wrought or cast aluminium
Tech Specs
Back To Top| Helix Angle | 45 Deg. |
|---|---|
| Overall Length Fractional | 2-1/8" |
| Overall Length Inches | 2.125" |
| Material | HSS Cobalt Powdered Metal |
| Shank Style | Cylindrical shank with Square |
| Coating/Finish | Bright |
| Cutting Direction | Right |
| Number of Flutes | 3 |
| Overall Length Metric | 53.98 mm |
| Brand | Dormer |
