M6 x 1.00 HSS Bright Finish LH Gun Nosed Die
- Item Code: 5977863
- Brand: Dormer
- Unit Size: 1
Description
Solid round die with a gun nose, for left hand ISO-Metric thread M6 with 1.00 mm pitch and 6g class of fit, dimensions according to ISO 2568 standard with 20mm outside diameter and 7mm thickness, HSS with bright finish for threading in free machining and plain carbon steel, ferritic stainless steel and gray, malleable, ductile and compacted graphite cast-iron
Tech Specs
Back To Top| Overall Length Inches | 0.2756" |
|---|---|
| Thread Size Metric | M6 x 1.00 |
| Cutting Direction | Left |
| Material | High Speed Steel |
| Coating/Finish | Bright |
| Brand | Dormer |
| Overall Length Metric | 7 mm |
