M8 x 1.25 HSS Bright Finish LH Gun Nosed Die
- Item Code: 5977866
- Brand: Dormer
- Unit Size: 1
Description
Solid round die with a gun nose, for left hand ISO-Metric thread M8 with 1.25 mm pitch and 6g class of fit, dimensions according to ISO 2568 standard with 25mm outside diameter and 9mm thickness, HSS with bright finish for threading in free machining and plain carbon steel, ferritic stainless steel and gray, malleable, ductile and compacted graphite cast-iron
Tech Specs
Back To Top| Overall Length Inches | 0.3543" |
|---|---|
| Brand | Dormer |
| Cutting Direction | Left |
| Coating/Finish | Bright |
| Material | High Speed Steel |
| Overall Length Metric | 9 mm |
| Thread Size Metric | M8 x 1.25 |
