M30 x 2.00 HSS Bright RH Rethreading Hex Die Nut
- Item Code: 5977952
- Brand: Dormer
- Unit Size: 1
Description
Adjustable circular split die, for ISO-Metric Fine thread M30 with 2.00 mm pitch, to reduce the torque when cutting by hand split dies can be adjusted in small increments up to a maximum of approximately 0.15mm, dimensions according to BS 1127:1950 standard with 2.1/4" outside diameter and 11/16" thickness, HSS with bright finish for threading in free machining and plain carbon steel, ferritic stainless steel and gray, malleable, ductile and compacted graphite cast-iron
Tech Specs
Back To Top| Thread Size Metric | M30 x 2.00 |
|---|---|
| Cutting Direction | Right |
| Overall Length Inches | 0.6875" |
| Material | High Speed Steel |
| Coating/Finish | Bright |
| Overall Length Metric | 17.46 mm |
| Brand | Dormer |
| Overall Length Fractional | 11/16" |
