1 in. HSS TiN Finish RH 90 Deg. Short Length Spotting Drill
- Item Code: 6000135
- Brand: Precision Twist Drill
- Unit Size: 1
Description
SPSG-90 spotting drills have a 90 degree conventional point including a 90 degrees accurate chamfer to accommodate standard screws, whilst the short, rigid design improves centering and accuracy. The drills are suitable for use in many common materials including steel, stainless steel, aluminum and cast iron and have a titanium nitride coating to increase the service life of the drill and improve performance when used to drill hard materials.
Tech Specs
Back To Top| Fractional Size | 1" |
|---|---|
| Metric Size | 25.40 mm |
| Overall Length Metric | 152.4 mm |
| Shank Style | Cylindrical shank |
| Brand | Precision Twist Drill |
| Decimal Size | 1.0000" |
| Cutting Direction | Right |
| Overall Length Fractional | 6" |
| Point Angle | 90 Deg. |
| Overall Length Inches | 6.0000" |
| Coating/Finish | TiN |
| Material | High Speed Steel |
