5/8 in. HSS TiN Finish RH 90 Deg. Short Length Spotting Drill
- Item Code: 6000154
- Brand: Precision Twist Drill
- Unit Size: 1
Description
SPSG-90 spotting drills have a 90 degree conventional point including a 90 degrees accurate chamfer to accommodate standard screws, whilst the short, rigid design improves centering and accuracy. The drills are suitable for use in many common materials including steel, stainless steel, aluminum and cast iron and have a titanium nitride coating to increase the service life of the drill and improve performance when used to drill hard materials.
Tech Specs
Back To Top| Decimal Size | 0.6250" |
|---|---|
| Overall Length Metric | 111.13 mm |
| Shank Style | Cylindrical shank |
| Coating/Finish | TiN |
| Material | High Speed Steel |
| Brand | Precision Twist Drill |
| Overall Length Fractional | 4-3/8" |
| Fractional Size | 5/8" |
| Metric Size | 15.88 mm |
| Cutting Direction | Right |
| Overall Length Inches | 4.375" |
| Point Angle | 90 Deg. |
