1 in. x 11.5 in. UNF Carbide Alcrona Pro Coated Finish RH 10 Deg. Spiral Flute Thread Mill Cutter
- Item Code: 6821348
- Brand: Dormer
- Unit Size: 1
Description
Thread milling cutter, for National Pipe Taper thread ? NPT 1'' with 11.5 TPI, dimensions according to DORMER standard with 5 flutes, 19.9mm cutting diameter and 20mm Weldon shank according to DIN 6535 HB, solid carbide with Alcrona Pro coating and 10? helix angle for milling a maximum of 27.12mm long right or left hand internal thread in steel and cast steel, stainless steel, cast-iron, non-ferrous metals, titanium or titanium alloys, chilled cast-iron
Tech Specs
Back To Top| Decimal Diameter | 0.7835" |
|---|---|
| Metric Diameter | 19.9 mm |
| Shank Style | Cylindrical shank DIN 6535 HB |
| Brand | Dormer |
| Helix Angle | 10 Deg. |
| Coating/Finish | Alcrona Pro |
| Material | Solid Carbide |
| Overall Length Inches | 3.622 |
| Cutting Direction | Right |
| Number of Flutes | 5 |
| Overall Length Metric | 92 mm |
