5.50 mm HSS Steam Tempered RH 120 Deg. Point Stub Length Drill

  • Item Code: 7189789
  • Brand: Dormer
  • Unit Size: 1

Description

Dormer?s A123 short drill in both fractional and metric sizes is specially designed for drilling thin materials and sheet metal. Manufactured from High Speed steel, it is suitable for drilling in many materials including steels, stainless steels and aluminium. The drill has a 120 degree point and a steam oxide finish which stops workpiece material from sticking to the cutting edge of the drill, giving you a better hole finish and more accurate diameter. The core of the A123 is thinner than normal which helps reduce the amount of force needed when drilling. A final design feature is the absence of any body clearance on the drill which improves hole roundness when drilling thin material.

ORDER IN MULTIPLES of 10

Tech Specs

Back To Top
Coating/Finish Steam Oxide
Decimal Size 0.2165"
Material High Speed Steel
Metric Size 5.50 mm
Shank Style Cylindrical shank
Brand Dormer
Overall Length Metric 66 mm
Flute Type Standard Spiral
Overall Length Inches 2.5984
Cutting Direction Right
Point Angle 120 Deg.
