6.80 mm HSS TiAIN 90 Deg. Point RH Spotting Drill
- Item Code: 7341682
- Brand: Dormer
- Unit Size: 1
Description
Step drill with 90? included step angle, DIN 6535HA parallel shank and a drilling-pilot diameter of 6.80mm with a length of 21.00mm, a countersink diameter of maximum 10.00mm and an overall length of 89mm, according to DORMER standard to produce a thread tapping drill hole with chamfer for M8 thread, solid carbide and bright finish for machining free machining, plain carbon, alloy and tool steel, ferritic, martensitic, austenitic and super-austenitic, Duplex or precipitation hardening stainless steel, grey, malleable, ductile, austenitic or austempered ductile and compacted graphite cast-iron, wrought and cast aluminium and copper or copper alloys
Tech Specs
Back To Top| Overall Length Inches | 3.5039 |
|---|---|
| Overall Length Metric | 89 mm |
| Brand | Dormer |
| Shank Style | Cylindrical shank DIN 6535 HA |
| Decimal Diameter | 0.2677" |
| Metric Diameter | 6.80 mm |
| Cutting Direction | Right |
| Flute Type | Standard Spiral |
| Coating/Finish | TiAlN |
| Material | Solid Carbide |
| Point Angle | 140 Deg. |
