3/8 Inch Drive 12 Point Deep SAE Socket 9/16 Inch

  • Item Code: 80514-GEARWRENCH
  • Brand: GearWrench
  • Unit Size: 1

Description

Features Tech Specs

Features

Back To Top
    • Surface Drive� Technology Reduces Fastener Rounding
    • Chamfered Opening to Guide Fastener Into Socket
    • Large Hard-Stamped Size Identification
    • Double Line (SAE) and Knurled (Metric) Ring to Easily Identify Standard vs. Metric Sockets
    • Full Polish Chrome Finish Cleans Easily and Resists Corrosion
    • Meets or Exceeds ASME B107.1 and US Federal Spec. GGG-W-641 E

Tech Specs

Back To Top
Dimension A Drive End 0.780 in
Dimension B Wrench End 0.780 in
Dimension C Overall Length 2.500 in
Dimension D Bolt Clearance 0.335 in
Dimension E Wrench Depth 0.350 in
Dimension F Length to Shoulder 1.142 in
Fastener Size 9/16 in
UPC 099575805141
ASME Specification B107.1
Weight (Catalog) 0.18 lb
Length Format Deep
Packaging Carded
Brand GearWrench
Country of Origin China
Drive Tang Size 3/8 in
Drive Type 12 Point
SAE/Metric/Torx SAE
Type Sockets
US Federal Specification GGG-W-641 E
