AGD15605 Grade CG5 A/B Grooving Insert

  • Item Code: AGD15605-CG5
  • Brand: WIDIA
  • Unit Size: 1

Description

Tech Specs

Tech Specs

Back To Top
Catalog Groove Width (Inch) 0.0500
Catalog Groove Width (Metric) 1.270
Lead Angle ANSI -2.500
Lead Angle ISO 92.500
Tool Length (Inch) 0.6000
Tool Length (Metric) 15.240
Tool Overall Length (mm) 29.210
Min Bore Diameter Metric 3.962 mm
Cutting Depth (Inch) 0.0500
Units of Tool (Extract) IN - Inch
Cutting Depth (Metric) 1.270
Brand WIDIA
Tool Overall Length (Inch) 1.1500
Min Bore Diameter Decimal 0.1560"
Tool Length (Fraction) 0.6000
Max Bore Depth Decimal 0.5000"
Max Bore Depth Metric 12.70 mm
