0.1560 Inch Dia. x 6.000 Inch Overall Length x 0.180 Inch Min Dia. S-Clamp RH Boring Bar

  • Item Code: CCBI16515667R-WG
  • Brand: WIDIA
  • Unit Size: 1

Description

Tech Specs

Tech Specs

Back To Top
Lead Angle -7 Degree
Shank Length 5.6160 Inch
Drive Size T6
Grade WG
Head Length 0.3840 Inch
Included Angle 80
Insert Style CCBI
Axial Rake Angle 0 Degree
Hand of Tool Right
Product Type Boring Bar
Shank Diameter 0.1560 Inch
Brand WIDIA
Cutting Height 0.0100 Inch
Unit of Measure Inch
Insert Shape Diamond
Min Bore Diameter 0.1800 Inch
Overall Length 4 Inch
Tool Length 6 Inch
