0.1880 Inch Dia. x 6.000 Inch Overall Length x 0.208 Inch Min Dia. S-Clamp RH Boring Bar

  • Item Code: CCBI18018765R-WG
  • Brand: WIDIA
  • Unit Size: 1

Description

Tech Specs

Tech Specs

Back To Top
Insert Shape Diamond
Cutting Height 0.0100 Inch
Head Length 0.4230 Inch
Unit of Measure Inch
Axial Rake Angle 5 Degree
Brand WIDIA
Hand of Tool Right
Lead Angle -5 Degree
Min Bore Diameter 0.2080 Inch
Overall Length 6 Inch
Shank Diameter 3/16 Inch
Grade WG
Insert Style CCBI
Drive Size T6
Included Angle 80
Product Type Boring Bar
Shank Length 5.5770 Inch
Tool Length 6 Inch
Head Diameter 0.1950 Inch
