5/8 Inch Shank Dia. x 0.1950 Inch Head Dia. x 3.375 Inch Overall Length x 0.208 Inch Min Dia. S-Clamp RH Boring Bar

  • Item Code: CCBI1806258755R WG
  • Brand: WIDIA
  • Unit Size: 1

Description

Tech Specs

Tech Specs

Back To Top
Head Diameter 0.1950 Inch
Insert Shape Diamond
Min Bore Diameter 0.2080 Inch
Overall Length 3.3750 Inch
Tool Length 3-3/8 Inch
Drive Size T6
Grade WG
Included Angle 80
Head Length 0.4230 Inch
Insert Style CCBI
Hand of Tool Right
Product Type Boring Bar
Axial Rake Angle 5 Degree
Brand WIDIA
Cutting Height 0.0100 Inch
Unit of Measure Inch
Coolant Through (Yes/No) Yes
Lead Angle -5 Degree
Shank Diameter 5/8 Inch
Shank Length 2.5000 Inch
