1/4 Inch Dia. x 4.000 Inch Overall Length x 0.285 Inch Min Dia. S-Clamp LH Boring Bar

  • Item Code: CCBI25045L-WG
  • Brand: WIDIA
  • Unit Size: 1

Description

Tech Specs

Tech Specs

Back To Top
Head Diameter 0.2630 Inch
Included Angle 80
Shank Diameter 1/4 Inch
Brand WIDIA
Cutting Height 0.0100 Inch
Overall Length 4 Inch
Unit of Measure Inch
Grade WG
Hand of Tool Left
Shank Length 3.5160 Inch
Min Bore Diameter 0.2850 Inch
Tool Length 4 Inch
Axial Rake Angle 5 Degree
Head Length 0.4840 Inch
Product Type Boring Bar
Drive Size T6
Insert Shape Diamond
Insert Style CCBI
Lead Angle -5 Degree
