1/4 Inch Dia. x 4.000 Inch Overall Length x 0.285 Inch Min Dia. S-Clamp RH Boring Bar

  • Item Code: CCBI25045R-WG
  • Brand: WIDIA
  • Unit Size: 1

Description

Tech Specs

Tech Specs

Back To Top
Head Length 0.4830 Inch
Axial Rake Angle 5 Degree
Shank Diameter 1/4 Inch
Brand WIDIA
Cutting Height 0.0100 Inch
Overall Length 4 Inch
Unit of Measure Inch
Included Angle 80
Min Bore Diameter 0.2850 Inch
Shank Length 3.5170 Inch
Tool Length 4 Inch
Insert Shape Diamond
Insert Style CCBI
Drive Size T6
Lead Angle -5 Degree
Grade WG
Hand of Tool Right
Product Type Boring Bar
