0.3120 Inch Dia. x 6.000 Inch Overall Length x 0.356 Inch Min Dia. S-Clamp RH Boring Bar

  • Item Code: CCBI31265R-WG
  • Brand: WIDIA
  • Unit Size: 1

Description

Tech Specs

Tech Specs

Back To Top
Insert Style CCBI
Min Bore Diameter 0.3560 Inch
Shank Diameter 0.3120 Inch
Insert Shape Diamond
Axial Rake Angle 5 Degree
Hand of Tool Right
Lead Angle -5 Degree
Overall Length 6 Inch
Head Length 0.5440 Inch
Product Type Boring Bar
Brand WIDIA
Cutting Height 0.0100 Inch
Included Angle 80
Unit of Measure Inch
Drive Size T6
Grade WG
Shank Length 5.4560 Inch
Tool Length 6 Inch
