1/4 Inch Dia. x 4.000 Inch Overall Length x 0.312 Inch Min Dia. S-Clamp RH Boring Bar

  • Item Code: CCMI25040R-WG
  • Brand: WIDIA
  • Unit Size: 1

Description

Tech Specs

Tech Specs

Back To Top
Head Diameter 0.2580 Inch
Insert Style CCMI
Min Bore Diameter 0.3120 Inch
Overall Length 4 Inch
Product Type Boring Bar
Shank Diameter 1/4 Inch
Grade WG
Insert Shape Diamond
Lead Angle 0 Degree
Shank Length 3.5160 Inch
Hand of Tool Right
Included Angle 80
Brand WIDIA
Cutting Height 0.0100 Inch
Head Length 0.4840 Inch
Unit of Measure Inch
Axial Rake Angle 0 Degree
Tool Length 4 Inch
Drive Size T6
