0.188 Inch Shank Dia. x 0.180 Inch Head Dia. x 2.500 Inch Overall Length x 0.204 Inch Min Dia. S-Clamp RH Boring Bar

  • Item Code: CSBI180187255R WG
  • Brand: WIDIA
  • Unit Size: 1

Description

Tech Specs

Tech Specs

Back To Top
Head Length 0.5000 Inch
Min Bore Diameter 0.2040 Inch
Insert Style CSBI
Grade WG
Tool Length 2-1/2 Inch
Hand of Tool Right
Product Type Boring Bar
Shank Diameter 3/16 Inch
Axial Rake Angle 5 Degree
Brand WIDIA
Cutting Height 0.0100 Inch
Unit of Measure Inch
Drive Size T6
Included Angle 80
Insert Shape Diamond
Shank Length 2 Inch
Coolant Through (Yes/No) Yes
Overall Length 2.5000 Inch
Lead Angle -5 Degree
