0.188 Inch Shank Dia. x 0.203 Inch Head Dia. x 2.500 Inch Overall Length x 0.228 Inch Min Dia. S-Clamp RH Boring Bar

  • Item Code: CSBI187255R
  • Brand: WIDIA
  • Unit Size: 1

Description

Tech Specs

Tech Specs

Back To Top
Min Bore Diameter 0.2280 Inch
Included Angle 80
Shank Length 2 Inch
Product Type Boring Bar
Drive Size T6
Grade WG
Tool Length 2-1/2 Inch
Insert Style CSBI
Coolant Through (Yes/No) Yes
Cutting Height 0.0100 Inch
Unit of Measure Inch
Insert Shape Diamond
Shank Diameter 3/16 Inch
Axial Rake Angle 5 Degree
Brand WIDIA
Hand of Tool Right
Lead Angle -5 Degree
Overall Length 2.5000 Inch
Head Length 0.5000 Inch
