1/2 Inch Shank Dia. x 0.203 Inch Head Dia. x 2.500 Inch Overall Length x 0.228 Inch Min Dia. S-Clamp RH Boring Bar

  • Item Code: CSBI20350015R-WG
  • Brand: WIDIA
  • Unit Size: 1

Description

Tech Specs

Tech Specs

Back To Top
Head Length 1 Inch
Axial Rake Angle 5 Degree
Brand WIDIA
Coolant Through (Yes/No) Yes
Shank Diameter 1/2 Inch
Unit of Measure Inch
Cutting Height 0.0075 Inch
Lead Angle -5 Degree
Shank Length 1.7500 Inch
Min Bore Diameter 0.2280 Inch
Insert Shape Diamond
Overall Length 2.7500 Inch
Product Type Boring Bar
Tool Length 2-3/4 Inch
Drive Size T6
Included Angle 80
Insert Style CSBI
Grade WG
Hand of Tool Right
