11.2mm Cyclone XD Coolant 3X Stub Length High Performance Drill ALtima Plus Coated
- Item Code: CXDCS 1120AP
- Brand: MA Ford
- Unit Size: 1
Description
Cyclone XD - Series CXDCS
Designed for high performance drilling in a broad range of materials.
ALtima® Plus- This Aluminum Titanium Nitride (AlTiN) multi-layer coating has optimized coating structure, with pre and post treatment of the coating for optimized high performance drilling in any ferrous material.
Features
Back To Top- Lower Thrust Point Geometry
- Enhanced Double Margin Design
Tech Specs
Back To Top| Cutting Depth | 40mm |
|---|---|
| Length of Cut | 55mm |
| Shank Diameter | 12mm |
| Helix Angle | 30° |
| Metric Diameter | 11.20 mm |
| Overall Length | 102mm |
| Brand | MA Ford |
| Decimal Diameter | 0.4409" |
| Type | Drill |
| Angle | 140°-142° |
| Material | Solid Carbide |
| Number of Flutes | 2 |
| Coating/Finish | AlTiN |
| Series | Cyclone XD |
