3.1mm Cyclone XD Solid 3X Stub Length High Performance Drill ALtima Plus Coated
- Item Code: CXDSS 0310AP
- Brand: MA Ford
- Unit Size: 1
Description
Cyclone XD - Series CXDSS
Designed for high performance drilling in a broad range of materials.
ALtima® Plus- This Aluminum Titanium Nitride (AlTiN) multi-layer coating has optimized coating structure, with pre and post treatment of the coating for optimized high performance drilling in any ferrous material.
Features
Back To Top- Lower Thrust Point Geometry
- Enhanced Double Margin Design
Tech Specs
Back To Top| Cutting Depth | 14mm |
|---|---|
| Length of Cut | 20mm |
| Overall Length | 62mm |
| Brand | MA Ford |
| Coating/Finish | AlTiN |
| Type | Drill |
| Material | Solid Carbide |
| Helix Angle | 30° |
| Number of Flutes | 2 |
| Angle | 140°-142° |
| Metric Diameter | 3.10 mm |
| Shank Diameter | 4mm |
| Series | Cyclone XD |
| Decimal Diameter | 0.1220" |
